GE L30

GE Multilin L30 Line Current Differential System B-61
APPENDIX B B.4 MEMORY MAPPING
B
C318 ...Repeated for Virtual Output 62
C320 ...Repeated for Virtual Output 63
C328 ...Repeated for Virtual Output 64
C330 ...Repeated for Virtual Output 65
C338 ...Repeated for Virtual Output 66
C340 ...Repeated for Virtual Output 67
C348 ...Repeated for Virtual Output 68
C350 ...Repeated for Virtual Output 69
C358 ...Repeated for Virtual Output 70
C360 ...Repeated for Virtual Output 71
C368 ...Repeated for Virtual Output 72
C370 ...Repeated for Virtual Output 73
C378 ...Repeated for Virtual Output 74
C380 ...Repeated for Virtual Output 75
C388 ...Repeated for Virtual Output 76
C390 ...Repeated for Virtual Output 77
C398 ...Repeated for Virtual Output 78
C3A0 ...Repeated for Virtual Output 79
C3A8 ...Repeated for Virtual Output 80
C3B0 ...Repeated for Virtual Output 81
C3B8 ...Repeated for Virtual Output 82
C3C0 ...Repeated for Virtual Output 83
C3C8 ...Repeated for Virtual Output 84
C3D0 ...Repeated for Virtual Output 85
C3D8 ...Repeated for Virtual Output 86
C3E0 ...Repeated for Virtual Output 87
C3E8 ...Repeated for Virtual Output 88
C3F0 ...Repeated for Virtual Output 89
C3F8 ...Repeated for Virtual Output 90
C400 ...Repeated for Virtual Output 91
C408 ...Repeated for Virtual Output 92
C410 ...Repeated for Virtual Output 93
C418 ...Repeated for Virtual Output 94
C420 ...Repeated for Virtual Output 95
C428 ...Repeated for Virtual Output 96
Mandatory (Read/Write Setting or Command)
C430 Test Mode Function 0 to 2 --- 1 F245 0 (Disabled)
C431 Force VFD and LED 0 to 1 --- 1 F126 0 (No)
C432 Test Mode Initiate 0 to 4294967295 --- 1 F300 1
Clear Commands (Read/Write)
C434 Clear All Relay Records Command 0 to 1 --- 1 F126 0 (No)
Mandatory (Read Only)
C435 DSP Advanced Diagnostics Active 0 to 1 -- 1 F126 0 (No)
C436 Synchrophasor Feature Active 0 to 1 -- 1 F126 0 (No)
Mandatory (Read/Write Command)
C437 Relay Reboot Command 0 to 1 --- 1 F126 0 (No)
C438 Save Volatile Data 0 to 1 --- 1 F126 0 (No)
Clear Records (Read/Write Setting)
C450 Clear Fault Reports Operand 0 to 4294967295 --- 1 F300 0
C454 Clear Event Records Operand 0 to 4294967295 --- 1 F300 0
C456 Clear Oscillography Operand 0 to 4294967295 --- 1 F300 0
C458 Clear Data Logger Operand 0 to 4294967295 --- 1 F300 0
C45A Clear Breaker 1 Arcing Current Operand 0 to 4294967295 --- 1 F300 0
C45C Clear Breaker 2 Arcing Current Operand 0 to 4294967295 --- 1 F300 0
Table B–10: MODBUS MEMORY MAP (Sheet 53 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
