B-62 L30 Line Current Differential System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
C466 Clear Channel Tests Status Operand 0 to 4294967295 --- 1 F300 0
C46C Clear Unauthorized Access Operand 0 to 4294967295 --- 1 F300 0
C472 Reserved (13 items) --- --- --- F001 0
Direct Input/Output Settings (Read/Write Setting)
C500 Direct Input Default States (8 items) 0 to 1 --- 1 F108 0 (Off)
C508 Direct Input Default States (8 items) 0 to 1 --- 1 F108 0 (Off)
C510 Direct Output x 1 Operand (8 items) 0 to 4294967295 --- 1 F300 0
C520 Direct Output x 2 Operand (8 items) 0 to 4294967295 --- 1 F300 0
Reset (Read/Write Setting)
C750 FlexLogic operand which initiates a reset 0 to 4294967295 --- 1 F300 0
Control Pushbuttons (Read/Write Setting) (7 modules)
C760 Control Pushbutton 1 Function 0 to 1 --- 1 F102 0 (Disabled)
C761 Control Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
C762 ...Repeated for Control Pushbutton 2
C764 ...Repeated for Control Pushbutton 3
C766 ...Repeated for Control Pushbutton 4
C768 ...Repeated for Control Pushbutton 5
C76A ...Repeated for Control Pushbutton 6
C76C ...Repeated for Control Pushbutton 7
Force Contact Inputs/Outputs (Read/Write Settings)
C7A0 Force Contact Input x State (96 items) 0 to 2 --- 1 F144 0 (Disabled)
C800 Force Contact Output x State (64 items) 0 to 3 --- 1 F131 0 (Disabled)
87L Channel Tests (Read/Write)
C840 Local Loopback Function 0 to 1 --- 1 F126 0 (No)
C841 Local Loopback Channel 1 to 2 --- 1 F001 1
C842 Remote Loopback Function 0 to 1 --- 1 F126 0 (No)
C843 Remote Loopback Channel 1 to 2 --- 1 F001 1
C844 Remote Diagnostics Transmit 0 to 2 --- 1 F223 0 (NO TEST)
Remote Devices (Read/Write Setting) (16 modules)
CB00 Remote Device 1 GSSE/GOOSE Application ID (GOID) --- --- --- F209 “Remote Device
1“
CB21 Remote Device 1 GOOSE Ethernet APPID 0 to 16383 --- 1 F001 0
CB22 Remote Device 1 GOOSE Dataset 0 to 16 --- 1 F184 0 (Fixed)
CB23 Remote Device 1 in PMU Scheme 0 to 1 --- 1 F126 0 (No)
CB24 Reserved 0 to 3 --- 1 F626 0 (None)
CB25 ...Repeated for Device 2
CB4A ...Repeated for Device 3
CB6F ...Repeated for Device 4
CB94 ...Repeated for Device 5
CBB9 ...Repeated for Device 6
CBDE ...Repeated for Device 7
CC03 ...Repeated for Device 8
CC28 ...Repeated for Device 9
CC4D ...Repeated for Device 10
CC72 ...Repeated for Device 11
CC97 ...Repeated for Device 12
CCBC ...Repeated for Device 13
CCE1 ...Repeated for Device 14
CD06 ...Repeated for Device 15
CD2B ...Repeated for Device 16
Remote Inputs (Read/Write Setting) (32 modules)
CFA0 Remote Input 1 Device 1 to 32 --- 1 F001 1
CFA1 Remote Input 1 Bit Pair 0 to 96 --- 1 F156 0 (None)
CFA2 Remote Input 1 Default State 0 to 3 --- 1 F086 0 (Off)
Table B–10: MODBUS MEMORY MAP (Sheet 54 of 63)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
