3-6 L30 Line Current Differential System GE Multilin
3.1 DESCRIPTION 3 HARDWARE
3
Figure 3–7: L30 VERTICAL SIDE MOUNTING REAR DIMENSIONS (STANDARD PANEL)
CUT-OUT
1.33"
(33.9)
2.83"
(71.9)
6.66"
(169.2)
12.20"
(309.9)
0.159" DIA. (6 PLACES)
(4.0)
0.213" DIA. (5.4)
(4 PLACES)
SEE HOLES MARKED 'X'
INCHES
(MILLIMETERS)
5.33"
(135.4)
PANEL SHOWN FOR
REFERENCE ONLY
(VIEWED FROM FRONT)
'X' 'X'
'X' 'X'
1.00"
(25.4)
1.00"
(25.4)
10.05
(255.3)
"
0.04
(1.0)
"
0.68"
(17.3)
5.27
(133.8)
"
843753A3.cdr
