GE LOGIQ V5/LOGIQ V3
D
IRECTION 5496012-100, REVISION 3 BASIC SERVICE MANUAL
4 - 18 Section 4-3 - General Procedure
Display Format No Changes the horizontal/vertical layout between B-Mode
and M-Mode, or timeline only.
Modify Auto Calcs No Activates the menu to select which calculations are
automatically calculated.
Auto Calcs No Activates the calculation automatically which you select
in the Modify Auto Calculation when the system is in a
state of freeze or live.
Simultaneous
(Duplex/Triplex)
Yes When you select Duplex or Triplex, everything is live.
For example, both B-Mode and PW/CW Doppler Modes
are active if Duplex is selected. When Triplex is
selected, B-Mode, PW/CW Doppler Mode, and CF
Doppler Modes are active.
If Duplex/Triplex is not selected, use M/D Cursor or
Update to toggle between modes.
Table 4-4 Doppler Mode Controls
Control Possible Bioeffect Description/Benefit
