GE LOGIQ V5

GE LOGIQ V5/LOGIQ V3
D
IRECTION 5496012-100, REVISION 3 BASIC SERVICE MANUAL
Chapter 4 - Functional Checks 4 - 1
Chapter 4
Functional Checks
Section 4-1
Overview
4-1-1 Purpose for Chapter 4
This chapter provides procedures for quickly checking major functions of the LOGIQ V5/LOGIQ V3
console, diagnostics by using the built-in service software, and power supply.
Section 4-2
Required Equipment
To perform these tests, you'll need any of the sector, linear, or convex transducers.
(normally you should check all the transducers used on the system)
Table 4-1 Contents in Chapter 4
Section Description Page Number
4-1 Overview 4-1
4-2 Required Equipment 4-1
4-3 General Procedure 4-2
4-4 Software Configuration Checks 4-32
4-5 Peripheral Checks 4-32
