GE LOGIQ V5 Service Manual

GE LOGIQ V5/LOGIQ V3
D
IRECTION 5496012-100, REVISION 3BASIC SERVICE MANUAL
Section 1-2 - Important Conventions 1 - 7
1-2-3 Product Icons
The following table describes the purpose and location of safety labels and other important information
provided on the equipment.
Table 1-6 Product Icons
LABEL/SYMBOL PURPOSE/MEANING LOCATION
Label/Icon Purpose/Meaning Location
Identification and Rating Plate • Manufacture’s name and address
• Date of manufacture
• Model and serial numbers
• Electrical ratings (Volts, Amps, phase, and frequency)
Refer to User manual for detailed
information.
Type/Class Label Used to indicate the degree of safety or protection.
IP Code (IPX8)
IPX8: FSU-1000, MKF 2-MED GP26
Indicates the degree of protection provided by the
enclosure per IEC60 529.
Bottom of footswitch
Type BF Applied Part (man in the box) symbol is in
accordance with IEC 60878-02-03.
Beside the probe connector
General Warning Various
“CAUTION” - Dangerous voltage” (the lightning flash
with arrowhead) is used to indicate electric shock
hazards.
Various
Indicates the power on and power off position of the
power switch.
CAUTION: This Power Switch DOES NOT ISOLATE
Mains Supply.
See the Console Overview section
for location information.
“Protective Earth” indicates the protective earth
(grounding) terminal.
Inside Console
This symbol indicates that waste electrical and
electronic equipment must not be disposed of as
unsorted municipal waste and must be collected
separately. Please contact an authorized representative
of the manufacturer for information concerning the
decommissioning of your equipment.
Bottom
