LX: OPM_MAE_XXX_2K2_3K0_XGB_V020 1 GE DE Match 2200-3000: user manual 2.0 (GB)
GE Digital Energy
g
USER MANUAL
Match
Uninterruptible Power Supply
Uninterruptible Power SupplyUninterruptible Power Supply
Uninterruptible Power Supply
2200 - 3000 VA
2200 - 3000 VA2200 - 3000 VA
2200 - 3000 VA
Please read these instructions carefully before installation and start-up of the Match UPS.
Keep this manual in a safe place for future reference.
CONTENTS
1 INTRODUCTION............................................................................................................2
1.1 Introduction
1.2 Safety Rules
1.3 Transport / Storage
2 INSTALLATION ..............................................................................................................2
2.1 Installation Rules
2.2 Installation Procedure
3 OPERATION...................................................................................................................4
3.1 Start-up
3.1.1 Start-up, mains available
3.1.2 Start-up, mains not available
3.2 Use: Normal Operation
3.2.1 Normal operating conditions
3.2.2 Load indication
3.2.3 Auto-off (no-load shutdown)
3.2.4 Battery test
3.2.5 Switching off
3.3 Use: Status and Alarm Indications
3.3.1 Charger on
3.3.2 Normal operation
3.3.3 AVR active
3.3.4 On battery
3.3.5 Battery low
3.3.6 Replace battery
3.3.7 Overload
3.3.8 High temperature
3.3.9 Programmed shutdown
4 COMMUNICATION ........................................................................................................7
4.1 RS232 Port
4.2 Relay Interface Card (option)
4.3 SNMP Interface Card (option)
5 OPTIONAL FEATURES.................................................................................................8
5.1 Extended Runtime
5.2 PowerFLAG SerVICe Box for Modem Connection
6 MAINTENANCE..............................................................................................................7
6.1 General
6.2 Batteries
6.3 UPS Configuration Tool
7 TROUBLESHOOTING ...................................................................................................9
8 SPECIFICATIONS........................................................................................................10
© General Electric Digital Energy. All rights reserved; reproduction without permission prohibited. This manual may be subject to
change; no liability can be accepted for any error or omission.
