GE Mini Telemetry

© 2010 by General Electric Company. All rights reserved. 2049809-001 Rev B 47
Appendix B
Transmitter
Category Technical Specications
RF Section
Power Output:
Channel Bandwidth:
Transmission Range:
Frequency Band : Power Output
420.0500 - 429.7375 MHz: 1mW
432.0000 - 438.0000 MHz: 4mW
440.5625 - 449.6625 MHz: 1mW
608.0250 - 613.9750 MHz: 4mW
Frequency Band : Channel Bandwidth
420.0500 - 429.7375 MHz : 12.5kHz
432.0000 - 438.0000 MHz : 25kHz
440.5625 - 449.6625 MHz : 12.5kHz
608.0250 - 613.9750 MHz : 25kHz
Frequency Band : Distance Coverage
420.0500 - 429.7375 MHz : 100m
432.0000 - 438.0000 MHz : 500m
440.5625 - 449.6625 MHz : 100m
608.0250 - 613.9750 MHz : 500m
Connectors:
DC inlet for charger
Audio head set
3 parametric connector ( US-FHR, UA, MECG/FECG )
Classication
Class IIb device under Rule 10 of Annex IX of the Council Directive 93/42/
EEC
(Line of Sight
*
)
* Un-obstructed path between transmitter and receiver antenna. Actual range may vary depending on the hospital infrastructure.
