© 2010 by General Electric Company. All rights reserved. 2049809-001 Rev B 49
Appendix B
Receiver
Category Technical Specications
RF Section
Input Impedance:
Input Sensitivity:
50 Ω
<0.4 µ V for 12 dB SINAD
Antenna Type: Flexible, detachable, BNC interconnect
(Other factory-approved external antennas or antenna systems
may be used. Contact your Information Technologies Service
Representative for more information.)
Controls: Power Switch, UA Mode Switch
Visual Indicators:
Power:
Signal Strength:
Transmitter Low/Depleted Battery:
Green LED
Green LED
Red LED
Connectors:
AC Line Input:
Auxiliary Output:
3-Prong, IEC-Style
Use only with Series 250 and 170 Monitors.
Classication Class IIb device under Rule 10 of Annex IX of the Council Directive
93/42/EEC
Product Compatibility
The system operates with the following Corometrics brand monitors. If your monitor is not listed, check with your
salesperson or service representative for a more current list.
120 Series
170 Series
250 Series
250cx Series
