3 SETUP AND USE Setpoints, Pg. 7
3-36
1
PAGE 7: SETPOINT VALUESPAGE 7: SETPOINT VALUES
METERING SETPOINTSMETERING SETPOINTS
This page is used to enable the 269 to display and/or trip and alarm on voltage or power values received
from a GE Multilin meter (MPM).
2
METERING SETPOINTS SETMETERING SETPOINTS SET
AND METER ON LINE? XXXAND METER ON LINE? XXX
This setpoint is used to enable 269 communication with a GE Multilin meter.
NOTE: CT and VT ratio must be programmed before "YES" is entered for this setpoint.
YES - 269 initiates communication and enables all page 7 setpoints as programmed.
NO - 269 no longer communicates with the meter and all page 7 setpoints are disabled.
Factory Value = NO
3
METER MODULEMETER MODULE
NOT INSTALLEDNOT INSTALLED
This message is shown when the answer to the question in the above setpoint is “NO”; i.e. the meter is
not online.
4
METER PHASE CTMETER PHASE CT
PRIMARY = XXX AMPSPRIMARY = XXX AMPS
Enter the phase CT primary value of the current transformers connected to the meter.
NOTE: Failure to enter a correct value for CT primary will result in incorrect values from the meter.
20-1500 (increments of 1)
Factory Value = 100
5
PHASE VT RATIOPHASE VT RATIO
VT RATIO = XXX:1VT RATIO = XXX:1
Enter the phase VT ratio of the voltage transformers connected to the meter.
VT ratio = VT primary / VT secondary (round to one decimal place).
NOTE: Failure to enter a correct value for VT ratio will result in incorrect values from the meter.
1-255 in steps of 1
Factory Value = 1
6
METER PHASE VT SECONDARYMETER PHASE VT SECONDARY
VT SECONDARY = XXX VOLTVT SECONDARY = XXX VOLT
Enter the VT secondary of the voltage transformer connected between the system and the meter. All
under and overvoltage protection is expressed as a percent of this setpoint.
40–240 (increments of 1)
Factory Value = 120
