GE MULTILIN 269 MOTOR MANAGEMENT RELAY Series User Manual

3 SETUP AND USE Setpoints, Pg. 1
3-18
Table 3-3 SETPOINTS
Page Line Information Line Setpoint Range and Units Manual Ref.
1 1
PAGE 1: SETPOINT VALUESPAGE 1: SETPOINT VALUES
MOTOR AMPS SETPOINTSMOTOR AMPS SETPOINTS
2
PHASE CT RATIOPHASE CT RATIO
CT SECONDARY = X AMPCT SECONDARY = X AMP
:1 or :5
Factory Value = 5
3.7
3
PHASE CT RATIOPHASE CT RATIO
CT PRIMARY = XXXX:XCT PRIMARY = XXXX:X
20-1500 (increments of 1)
Factory Value = 100
3.7
4
MOTOR FULL LOAD CURRENTMOTOR FULL LOAD CURRENT
FLC= XXXX AMPSFLC= XXXX AMPS
10-1500 amps (increments of 1)
Factory Value = 10
3.7
5
O/L PICKUP LEVEL O/L PICKUP LEVEL
LEVEL = 1.05 x FLCLEVEL = 1.05 x FLC
1.05-1.25 ×FLC (increments of
0.01)
Factory Value = 1.05
3.18,3.20
6
ACCEL.TIME= XXX.X SECONDSACCEL.TIME= XXX.X SECONDS
Consult motor data sheetConsult motor data sheet
0.5-125.0 or OFF
(increments of 0.5)
Factory Value = 10.0
3.8
7
STARTS/HOUR= XSTARTS/HOUR= X
Consult motor data sheetConsult motor data sheet
1-5 starts or OFF
(increments of 1)
Factory Value = 3
3.9
8
UNBALANCE ALARM LEVELUNBALANCE ALARM LEVEL
U/B ALARM= XX PERCENTU/B ALARM= XX PERCENT
4-30 % or OFF (increments of 1)
Factory Value = 10
3.10
9
U/B ALARM TIME DELAYU/B ALARM TIME DELAY
TIME DELAY = XXX SECTIME DELAY = XXX SEC
3-255 seconds (increments of 1)
Factory Value = 5
3.10
10
UNBALANCE TRIP LEVELUNBALANCE TRIP LEVEL
U/B TRIP= XX PERCENTU/B TRIP= XX PERCENT
4-30 % or OFF
(increments of 1)
Factory Value = 15
3.10
11
U/B TRIP TIME DELAYU/B TRIP TIME DELAY
U/B DELAY= XXX SECONDSU/B DELAY= XXX SECONDS
3-255 seconds (increments of 1)
Factory Value = 5
3.10
12
G/F CT RATIO :5 ? XXXG/F CT RATIO :5 ? XXX
(NO indicates 2000:1)(NO indicates 2000:1)
YES (5 amp secondary)
or NO (GE Multilin’s 50:0.025A
CT w/ ratio of 2000:1)
Factory Value = NO
3.11
13
•
GROUND CT PRIMARYGROUND CT PRIMARY
GROUND CT = XXX:5GROUND CT = XXX:5
20–1500 (increments of 1)
(Not seen if ratio is 2000:1)
Factory Value = 100
3.11
14
GROUND FAULT ALARM LEVELGROUND FAULT ALARM LEVEL
G/F ALARM= XXX AMPSG/F ALARM= XXX AMPS
50:0.025A (2000:1 ratio) CT:
1.-10 amps or OFF
(increments of 1)
Factory Value = 4
3.11
15
•
GROUND FAULT ALARM LEVELGROUND FAULT ALARM LEVEL
G/F ALARM= XXX xCTG/F ALARM= XXX xCT
5 A secondary CT: 0.1-1.0 xCT
rating or OFF (increments of
0.1)
(not seen if ratio is 2000:1)
Factory Value = 0.4
3.11
