GE MULTILIN 269 MOTOR MANAGEMENT RELAY Series User Manual

Setpoints, Pg. 1 3 SETUP AND USE
3-19
Page Line Information Line Setpoint Range and Units Manual Ref.
1 16
G/F ALARM TIME DELAYG/F ALARM TIME DELAY
TIME DELAY = XXX SECTIME DELAY = XXX SEC
1-255 seconds (increments of 1)
Factory Value = 10
3.11
17
GROUND FAULT TRIP LEVELGROUND FAULT TRIP LEVEL
G/F TRIP = XXX AMPSG/F TRIP = XXX AMPS
50:0.025A (2000:1 ratio) CT:
1.0-10.0 amps or OFF
(increments of 1.0)
Factory Value = 8
3.11
18
•
GROUND FAULT TRIP LEVELGROUND FAULT TRIP LEVEL
G/F TRIP = XXX xCTG/F TRIP = XXX xCT
5 A secondary CT: 0.1-1.0%
xCT rating or OFF (increments
of 0.1)
(not seen if ratio is 2000:1)
Factory Value = 0.8
3.11
19
G/F TRIP TIME DELAYG/F TRIP TIME DELAY
G/F DELAY= XX.X SECONDSG/F DELAY= XX.X SECONDS
0.0 (Instantaneous) - 20.0 sec-
onds (increments of 0.5). Addi-
tional time delay of 0.25 seconds
following 20.0.
Factory Value = 0.0
3.11
20
UNDERCURRENT ALARM LEVELUNDERCURRENT ALARM LEVEL
U/C ALARM= XXXX AMPSU/C ALARM= XXXX AMPS
1-1000 amps or OFF (incre-
ments of 1)
Factory Value = OFF
3.12
21
UNDERCURRENT ALARM DELAYUNDERCURRENT ALARM DELAY
TIME DELAY= XXX SECONDSTIME DELAY= XXX SECONDS
1-255 seconds (increments of 1)
Factory Value = 10
3.12
22
UNDERCURRENT TRIP LEVELUNDERCURRENT TRIP LEVEL
U/C TRIP = OFF AMPSU/C TRIP = OFF AMPS
1–1000 amps or OFF (incre-
ments of 1)
Factory Value = OFF
3.12
23
UNDERCURRENT TRIP DELAYUNDERCURRENT TRIP DELAY
TIME DELAY= XXX SECONDSTIME DELAY= XXX SECONDS
1–255 seconds (increments of 1)
Factory Value = 5
3.12
24
MECHANICAL JAM ALARMMECHANICAL JAM ALARM
ALARM LEVEL= XXX xFLCALARM LEVEL= XXX xFLC
1.5–6.0 xFLC or OFF (incre-
ments of 0.5)
Factory Value = OFF
3.13
25
MECH. JAM ALARM TIMEMECH. JAM ALARM TIME
DELAY = XXX.X SECONDSDELAY = XXX.X SECONDS
0.5–125.0 seconds (increments
of 0.5)
Factory Value = 5.0
3.13
26
RAPID TRIP / MECH. JAMRAPID TRIP / MECH. JAM
TRIP LEVEL= X.X x FLC TRIP LEVEL= X.X x FLC
1.5×FLC-4.5×FLC or OFF (incre-
ments of 0.5×FLC)
Factory Value = 2.5
3.13
27
RAPID TRIP TIME DELAYRAPID TRIP TIME DELAY
DELAY= XXX.X SECONDSDELAY= XXX.X SECONDS
0.5-125.0 seconds (increments
of 0.5)
Factory Value = 10.0
3.13
28
SHORT CIRCUIT TRIP LEVELSHORT CIRCUIT TRIP LEVEL
S/C TRIP= XX x FLCS/C TRIP= XX x FLC
4×FLC-12×FLC or OFF (incre-
ments of 1×FLC)
Factory Value = OFF
3.14
29
SHORT CIRCUIT TIME DELAYSHORT CIRCUIT TIME DELAY
S/C DELAY= XX.X SECONDSS/C DELAY= XX.X SECONDS
Instantaneous or 0.5-20.5 sec-
onds (increments of 0.5)
Factory Value = INST
3.14
