3 SETUP AND USE
3-53
Table 3-5 Standard Overload Curve Trip Times (in seconds)
Overload GE Multilin Standard Curve Number
Level 1 2 3 4* 5 6 7 8
1.05 853 1707 2560 3414 5975 7682 10243 12804
1.10 416 833 1249 1666 2916 3749 4999 6249
1.20 198 397 596 795 1391 1789 2385 2982
1.30 126 253 380 507 887 1141 1521 1902
1.40 91 182 273 364 637 820 1093 1366
1.50 70 140 210 280 490 630 840 1050
1.75 42 84 127 169 296 381 508 636
2.00 29 58 87 116 203 262 349 436
2.25 21 43 64 86 150 193 258 322
2.50 16 33 49 66 116 149 199 249
2.75 13 26 39 53 92 119 159 198
3.00 10 21 32 43 76 98 131 163
3.50 7 15 23 30 54 69 92 115
4.00 5 11 17 23 40 52 69 87
4.50 4 9 13 18 31 40 54 67
5.00 3 7 10 14 25 32 43 54
5.50 2 5 8 11 20 26 35 43
6.00 2 4 7 9 17 22 29 36
6.50 2 4 6 8 14 18 24 30
7.00 1 3 5 7 12 16 21 27
7.50 1 3 4 6 10 13 18 22
8.00 1 2 3 5 9 11 15 19
* - Factory preset value
