14 3 SERIES RETROFIT – INSTRUCTION MANUAL
MIW AND MIW II RELAYS CHAPTER 1: OVERVIEW
The following table describes MIW and MIW II options, and the equivalent 350 options and
order codes. In some cases the 350 options have changed from those available for MIW
and MIW II relays, so read the descriptions carefully.
Note
Order codes are subject to change without notice. See the GE Multilin website at: http://
www.gegridsolutions.com/multilin for up-to-date order codes.
Feature MIW order code options MIW II order code options 350 order code options
Function n/a MIWII-1-000E00HI00
1
1
: 3x Directional Power, 1x Loss of
Field, 1x Fuse Failure
2: 4x Directional Power
350EP0G0HEEN-W-SNNN
W: Advanced Protection: 27P(2),
27X(1), 27P_1 (1), 59P(2), 59N(1),
59X(1), 59_2(1), 81O(2), 81U(2),
67P(1), 67N(1), 67G/SG(1), VTFF(1),
25(1), 60CTS, 32(2)
Power Supply MIW1000E000-F-00C
H:
110 - 250 VDC (Range: 88~300 VDC)
110 - 230 VAC (Range: 88~264 VAC)
F: 24 - 48 VDC (Range: 19~58 VDC)
MIWII1000E00-HI-00
HI:
110 - 250 VDC (Range: 88~300 VDC)
110 - 230 VAC (Range: 88~264 VAC)
LO: 28 - 48 VDC (Range: 19~58 VDC)
350EP0G0-H-EENWSNNN
H: 110 - 250 VDC
110 - 230 VAC
L: 28 - 48 VDC
1. To replace model MIW II 1000 and the Loss of Excitation protection function, refer to the 889 Instruction Manual.
