16 3 SERIES RETROFIT – INSTRUCTION MANUAL
239 RELAYS CHAPTER 1: OVERVIEW
The following table describes 239 options, and the equivalent 339 options and order codes.
In some cases the 339 options have changed from those available for 239 relays, so read
the descriptions carefully.
NOTE
Note
Order codes are subject to change without notice. See the GE Multilin website at: http://
www.gegridsolutions.com/multilin for up-to-date order codes.
Feature 239 order code options 339 order code options
Application 239RTD-AN-H
AN: Single isolated, analog output:
0 – 1, 0 – 20, 4 – 20 mA
Programmable output parameters:
thermal capacity,% full load, phase
current, RTD1, RTD2, RTD3 temperature
339EP0G0HE-S-NNSNNH
S: Standard configuration: 37, 46, 48, 49,
50P(1), 50G/SG(1), 50N(1), 50L,51R, 66,
86, 51N(1), 51P(1), 50BF
Phase CT
Range
239 standard phase CT Input:
1 A and 5 A secondary
Range: 0.1 to 11 x phase CT primary
339E-P0-G0HESNNSNNH
P0: user selectable 1/5 A three-phase
current inputs (0.02 - 20 × CT)
Ground CT
Range
239 standard ground CT input:
5 A secondary and 50:0.025
Range:
0.03 to 1.4 x CT primary (5 A CT)
0.05 to 16.0 A (50:0.025 CT)
339EP0-G0-HESNNSNNH
G0: user selectable 1/5 A Ground current
input (0.02 - 20 × CT)
All 339 relays come with CBCT (50:0.025)
standard.
Power
Supply
239 standard power supply:
90 – 300 VDC or 70 – 265 VAC,
50 / 60 Hz
339EP1G1-H-ESNNSNNH
H: 110 - 250 VDC
110 - 230 VAC
L: 28 - 48 VDC
Harsh
Environment
239RTDAN-H
H: Harsh Environment Conformal
Coating
339EP1G1HESNNSNN-H
H: Harsh Environment Conformal
Coating
RTDs 239-RTD-ANH
3 RTDs: stator/bearing; programmable
type: platinum, nickel, copper
The 339 can support 3 - 100 ohm Pt
RTDs.
The RMIO module supports up to
12 - 100 ohm Pt RTDs.
