50 3 SERIES RETROFIT – INSTRUCTION MANUAL
P40 AGILE DIMENSIONS CHAPTER 3: INSTALLING THE 3 SERIES RELAY
Figure 3-12: P40 Agile P14x 30TE case dimensions
151.0mm
159.0mm 168.0mm
129.5mm 10.75
8 holes
3.4mm
23.7mm 103.6mm
154.2mm
177.0mm
213.1mm
242.7mm
AA
AA
BB
BB
A = Clearance hole
B = Mounting hole
E01404
