4.7.1 239 to 339 Retrofit Wiring
Table 4–19:
239 Terminal Wiring Connection 339 Terminal
1 Phase A CT 5A E5
2 Phase A CT 1A E5
3 Phase A CT COM D5
4 Phase B CT 5A E6
5 Phase B CT 1A E6
6 Phase B CT COM D6
7 Phase C CT 5A E7
8 Phase C CT 1A E7
9 Phase C CT COM D7
10 Ground CT 5A E8
11 Ground CT 50:0.025 E8
12 Ground CT COM D8
13 Safety ground Chassis Ground/
GND Stud
14 Filter ground Chassis Ground
15 RS485 A+ C3
16 RS485 B+ C4
17 RS485 ground C5
18 Analog out + Not Applicable
19 Analog out - Not Applicable
20 Analog out shield Not Applicable
21 Thermistor in + Not Applicable
22 Thermistor com Not Applicable
23 Trip NO A1
24 Trip COM A2
25 Trip NC May Use Aux 4
Contact
26 Alarm NO A12
27 Alarm COM A11
28 Alarm NC A10
29 Auxiliary NO A15
30 Auxiliary COM A14
31 Auxiliary NC A13
32 Service NO A21
33 Service COM A20
34 Service NC A19
35 V1 Polarizing (MOD 509) Note 1
36 Control live (+) L
37 Control neutral (-) N
38 Sw com B11
39 Sw com B11
40 Sw com B11
41 Sw com B11
42 Sw com B11
