3-56 F650 Digital Bay Controller GEK-113000T
3.2 HUMAN MACHINE INTERFACE (HMI) 3 HUMAN INTERFACES. SETTINGS & ACTUAL VALUES
3
<DETAILS>
The Details screen provides access to metering values, and date and time related with the event.
The top of the screen displays a legend with the event text, followed by the date and time, the event status (ON or
OFF), and the event index number related to the complete list of events in the relay, for example (1/479). The rest of
information provided by the Details screen corresponds to the relay measures in the moment of the event. Metering
values provided in the events are secondary, and voltage values correspond to phase-to-ground voltage.
Figure 3–30: SNAPSHOT EVENTS DETAIL SCREEN
To navigate this screen the user must follow the legend at the bottom of the screen:
Intro: Meters. ESC: Prev. L-R: Scroll.
Intro: Meters.
To access the metering values in the moment of the event, the user must press the shuttle key. A new metering screen
will be displayed, containing the primary metering values in the snapshot event, such as:
Once inside the Metering screen, a new legend will be shown for each event (Intro or ESC: Prev. L-R: Scroll); this
legend indicates that by pressing ESC or the shuttle key, the system will return to the Event Detail screen, and rotating
the shuttle key the user will access all the metering values contained in the metering screen of the considered event.
ESC: Prev.
If the user presses the ESC key from the event detail screen, the system will return to the all events screen.
Phasor Ia Primary I2 Primary
Phasor Ib Primary Vab Primary
Phasor Ic Primary Vbc Primary
Line Frequency Primary Vca Primary
Phasor Ig Primary V1 Primary
Phasor Isg Primary V2 Primary
I0 Primary V0 Primary
I1 Primary 3 Phase Power Factor
Ready LED ON
Date: 07/Nov/2004 St:ON
Time: 16:11:08.035 (1/479)
Phasor Ia Primary 0.000
Phasor Ib Primary 0.000
Phasor Ic Primary 0.000
Line Frequency 0.000
Phasor Ig Primary 0.000
Phasor Isg Primary 0.000
I0 Primary 0.000
I1 Primary 0.000
Intro: Meters. ESC: Prev. L-R: Scroll.
