2-28 F650 Digital Bay Controller GEK-113000T
2.4 TECHNICAL SPECIFICATIONS 2 PRODUCT DESCRIPTION
2
Protocols available:
ModBus
®
RTU / DNP 3.0
Typical distance: 1200 m
Isolation: 2 kV
CAN PORT:
Rear port: CAN port in models X, Y, Z for asynchronous rear ports
Type: Multimode glass F.O. port with ST connectors
Fiber Wave length: 1300 nm
Fiber type:
multimode 62.5/125 µm or 50/125 µm
Maximum recommended length 500m
Isolation: 2 kV
ETHERNET PORT:
Rear port: COM3
Type (depending on model):
Model B: 10/100BaseTX self-negotiable
Model C: 10/100BaseTX + 100Base FX
Model D: 10/100BaseTX + redundant 100BaseFX (Physical media redundancy)
Model E: Redundant 10/100BaseTX self-negotiable ports
10/100BaseTX RJ45 connector
100BaseFX ST connectors
Wave length: 1300 nm
Fiber type:
multimode 62.5/125 µm or 50/125 µm
Protocols available: ModBus® TCP/IP
DNP over TCP/IP and UDP/IP
IEC 61850
Http, ftp, tftp (allow the use of a standard Internet browser)
Typical distance: 1.65 km
Response time to ModBus commands: 10 ms Typical
Isolation: 2 kV
In Models C and D, the 10/100BaseTX port is selected by an internal switch (see 3.3.3)
Two witness LED’s for transmission and reception are included
