3 HUMAN INTERFACES. SETTINGS & ACTUAL VALUES 3.1 ENERVISTA 650 SETUP SOFTWARE INTERFACE
3
Table 3–1: TYPES OF FILES GENERATED BY ENERVISTA 650 SETUP SOFTWARE OPERATION MODE OFF-LINE:
In case of using element libraries (either existing (“File Library>Open Library”) or created by the user (“File Library>New
Library”), the program will create and manage the corresponding files (*.lib) in a folder named FDB (Functional Block
Diagram). These files are used for the PLC project compilation. It is necessary to store them with the other logic
configuration files that built the PLC project (*.pep, *.aut, *.lib).
Besides sending basic information to the relay (Settings + configuration) in *.650 format, it is recommended to store *.650,
*.pep, *.aut and *.lib files inside the relay (“Communication>Upload info files to relay”), to ensure that logic configuration
files will be available in the future for further logic modifications; either if these files are not used by the relay, they are
required for connecting to a relay and analyzing its configuration. The program manages the logic configuration files
globally, so that when the user selects to save file *.pep in the relay, the associated *.aut and *.lib files are also stored.
SETTINGS & CONFIGURATION FILE *.650
LOGIC CONFIGURATION FILES (*.PEP, *AUT, *.LIB)
*.PEP *.AUT *.LIB
Description Protection Settings and Configuration Section
Header for Logic
project
Graphical edition
container. Logic
equations (Virtual
Outputs) in FDB
format.
User programmable
logic objects
Created by EnerVista 650 Setup
Logic configuration
graphic editor (PLC
Editor)
Logic configuration
graphic editor (PLC
Editor)
Logic configuration
graphic editor (PLC
Editor)
Contents
Relay configuration file containing all protection
elements Settings, input/output and LEDs configuration,
graphic display configuration, etc.
Equations corresponding to the logic created and
compiled in the PLC Editor
PLC project file
containing the
necessary
information relative
to the relay model,
logic libraries
included in the
project (*.lib),
graphic file name
(*.aut), etc.
PLC Project file
containing all the
drawings used by
the logic, required by
650 relay based on
IEC 61131-3
standard. Functional
block diagram
(FDB).
Library file to be
included as an
object in a PLC
project. Logic
packages that can
be stored into
libraries and be
distributed in
different PLC
projects.
How to save
EnerVista 650 Setup:
“File>Save *”
PLC Editor:
“File>Save
Project”
PLC Editor:
“File>Save
Project”
PLC Editor:
“File>Save
Library”
How to open
EnerVista 650 Setup:
“File>Open *”
PLC Editor:
“File>Open
Project”
PLC Editor:
“File>Open
Project”
PLC Editor:
“File>Library>New
Library”
How to
transfer to
relay
Connect with the relay
(“Communications>Computer”)
Open the created file (“File>Open *”)
Send to relay from the menu: “F
ile>Send info to relay”
Note that texts used in the configuration of inputs,
outputs, etc. are not sent to the relay. The only texts
sent to relay are operations, events, and LEDs.
Connect with the relay (“Communications>Computer”)
Launch Logic equations Editor (“Setpoint>Logic
Configuration”)
Open the created PLC project (“File>Open Project”)
Compile the project (“Run>Compile”)
Now the logic (virtual outputs) can be sent directly to relay
(“Run>Send Equations to Relay”). Texts of virtual outputs are
not stored in the relay, only in the logic configuration files to be
edited.
File storage inside the relay
(RECOMMENDED)
“Communication > Upload info files to relay” through Ethernet
Retrieval of files stored in the relay
(RECOMMENDED)
“Communication > Download info files from relay” through Ethernet
