3-42 F650 Digital Bay Controller GEK-113000T
3.2 HUMAN MACHINE INTERFACE (HMI) 3 HUMAN INTERFACES. SETTINGS & ACTUAL VALUES
3
3.2.5.6 VIEW SETTINGS
To enter this menu press the shuttle key when the option “View Settings” is selected in main menu (). A secondary level
will be displayed with different sublevels as shown on Table 3–30:. Rotating the shuttle key, (left for moving up and right for
moving down) select the next level to be displayed (), press the shuttle key again to enter in next level and press esc key
to return to previous level if desired. This navigation will be performed the same for all the menus in “View Settings”. Once
the last sublevel is reached, move up and down to visualize the settings selected.
Table 3–30: GENERAL OVERVIEW OF “VIEW/CHANGE SETTINGS” MAIN MENU
MAIN SETTINGS MENU FIRST LEVEL SECOND LEVEL THIRD LEVEL
Product Setup >
Communication >
Serial Ports
Ethernet >
Ethernet 1
Ethernet 2
ModBus Protocol
DNP3 Slave (Available for
standard and IEC61850
models)>
DNP3 Slave 1
DNP3 Slave 2
DNP3 Slave 3
IEC 870-5-104(Available for
standard and IEC61850
models)>
SNTP
PROCOME (Available for
procome models only).
Fault Report
Oscillography
Demand
System Setup >
General Settings
Breaker >
Breaker Settings
Breaker Maintenance
Protection Element >
Phase Current >
Phase TOC High >
Phase TOC High 1
Phase TOC High 2
Phase TOC High 3
Phase TOC Low >
Phase TOC Low 1
Phase TOC Low 2
Phase TOC Low 3
Phase IOC High >
Phase IOC High 1
Phase IOC High 2
Phase IOC High 3
Phase IOC Low >
Phase IOC Low 1
Phase IOC Low 2
Phase IOC Low 3
Phase Directional >
