NX-4 Control
Page 18
Segment 4: 1 - On if Fail To Communicate report enabled.
2 - On if Log Full report enabled.
3 - On if Autotest report enabled.
4 - On if Start/End programming report enabled.
5 - On if End Download report enabled.
6 - On if Sensor Low Battery report enabled.
7 - On if Sensor Missing report enabled.
8 - Reserved.
Segment 5: 1 = On enable Lost Clock service light.
2 = On enables Zone Doubling (Must have extra devices added to basic system to enable, refer to
page 7) (NX-200 Zone Doubling Kit required)
3 = On disables On-Board 4 zones.
4 = On will allow two trips on same cross-zone to activate an alarm.
5 = On will not allow zones that are force armed to report bypass.
6 = Reserved.
7 = Use internal crystal for clock.
8 = Disable Temporal Siren on Fire (NOTE: For UL installations, do NOT disable
.) Refer to the
feature definitions beginning on page 3.
LOCATION 38 - SWINGER SHUTDOWN COUNT
Location 38 contains the number of trips on a zone before that zone is bypassed automatically. Refer to the feature
definitions beginning on page 3. Factory default is 1.
LOCATION 39 - KEYPAD SOUNDER CONTROL (1 segment, feature selection data)
Segment 1: 1 & 2 - Reserved.
3 - On if keypad sounds upon AC Power Failure.
4 - On if keypad sounds when a Low Battery is detected.
5 - On if keypad sounds during Cross Zone trip time.
6 - On if keypad sounds for zone and box tampers.
7 - Reserved.
8 - On if keypad sounds for expander trouble (required for UL installations).
LOCATION 40 - SYSTEM TIMERS (10 segments, numerical data)
Location 40 contains the duration of various system timing functions. Example: If you desire the duration of the
Dynamic Battery Test to be 30 minutes, you should program [3]-[0]-[r] in segment 1 of this location. The [3]-[0] is
the number of minutes, and the [r] stores the data and moves to the next segment of this location.
Segment 1 Dynamic Battery Test duration in minutes 0-255 minutes. (Default is 0 = no test)
Segment 2 AC Fail report delay in minutes 0-255 minutes. (Default is 5 minutes)
Segment 3 Power Up Delay in seconds 0-60 seconds (0 = no power up delay). (Default is 60 seconds)
Segment 4 Siren Time in minutes 1-255 minutes. (Default is 8 minutes)
Segment 5 Reserved.
Segment 6 Cross Zone time in minutes 0-255. (0 = no cross zoning) (Default is 5 minutes)
Segment 7 Chime time in 50mS (1/20th second) increments from 0-12 seconds. (0 = follows zone 255 latched).
Segment 8 Dial delay in seconds 15-255 seconds. (Default is 30 seconds)
Segment 9 Fire Alarm Verification time in seconds 120-255 seconds. (Default is 0 = no verification)
Segment 10 Listen-In time in seconds 0-255. (Default is 0 = no Listen-In time)
IMPORTANT NOTES
1. The "Listen-In" feature cannot be enabled for UL Listed systems. The "Dynamic Battery Test" feature cannot
exceed four (4) hours. The dial delay shall be set to “0".
2. For household systems, the Fire Alarm Verification feature is NOT approved for use in California. This feature
shall not be programmed into the control unit.

GE NetworX NX-4 Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP

Operating Environment

loop resistance	300 Ohms Maximum
loop response	500mS
operating temperature	32 to 120 degrees F

Weight and Dimensions

led keypad dimensions	6.4" Wide, 4.0" High, 1.1" Deep
nx-148e lcd keypad dimensions	6.4" Wide, 5.3" High, 1.0" Deep
metal enclosure dimension	9.25" Wide, 8.25" High, 3.50" Deep
