NX-4 Control
Page 20
AUXILIARY OUTPUT EVENT SELECTION
DATA EVENT DATA EVENT
0 / Burglary Alarm 26 Fire Trouble
1 / Fire Alarm 27 Chime
2 / 24 Hour Alarm 28 / Expander Trouble
3 / Trouble Alarm 29 Dynamic Battery Test Time
4 / Tamper Alarm 30 Open Period
5 Yelping Siren (Burglary) 31 Closed Period
6 Temporal Siren (Fire) 32 Listen-In
7 Any Siren 33 Line Seizure
8 Any Bypass 34 Ground Start
9 AC Fail 35 Fail To Communicate
10 Low Battery 36 Reserved
11 / Duress 37 Program Mode
12 / Aux 1 Keypad Zone 38 Download In Process
13 / Aux 2 Keypad Zone 39 Reserved
14 / Panic Keypad Zone 40 Short Circuit (Over-current)
15 Keypad Tamper 41 Box Tamper
16 / Autotest 42 Siren Tamper
17 Alarm Memory 43 Any Open
18 Entry 44 Any Short
19 Exit 45 Any Fault (Open/ Short on Non-Fire Zone)
20 Entry or Exit 46 / Any Alarm
21 Armed State 47 Beeping Keypad
22 Disarmed State 48 / Code Entry (See note below)
23 Ready 49 ˜ / Key FOB Function 1
24 Not Ready 50 ˜ / Key FOB Function 2
25 Fire
Notes: When Event 48 is programmed, it is possible to program a user code's authorization to select which output(s)
a particular code will activate. When LED 8 is on for an authorization, then LEDs 1- 2 correspond to that code
activating outputs 1 & 2 respectively. (See programming the LED keypads on page 8.)
˜ Events 49 & 50 require NX-408E, NX-416E or NX-448E wireless receivers to operate.
/ If set to follow condition, these events will be 1 second.
LOCATION 51 - AUTOTEST CONTROL (4 segments, numerical data)
Segment 1: Program a "1" if the interval is to be in hours; Program a "0" if in days. Add a A2" to suppress the
daily test or a A3" to suppress the hourly test if any report has been sent.
Segment 2: Program the Autotest interval from 1-255 hours/days.
Segment 3: Program the Autotest report hour in 24-hour format (if the interval is in hours, this segment is
ignored).
Segment 4: Program the Autotest report time, number of minutes after the hour.

GE NetworX NX-4 Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP

Operating Environment

loop resistance	300 Ohms Maximum
loop response	500mS
operating temperature	32 to 120 degrees F

Weight and Dimensions

led keypad dimensions	6.4" Wide, 4.0" High, 1.1" Deep
nx-148e lcd keypad dimensions	6.4" Wide, 5.3" High, 1.0" Deep
metal enclosure dimension	9.25" Wide, 8.25" High, 3.50" Deep
