GE NetworX NX-4 User Manual

NX-4 Control
Page 21
LOCATION 52 - OPENING TIME (2 segments, numerical data)
Location 52 contains the time in 24 hour format the NX-4 enables codes designated as arm only after closing. This
time is only valid on those days programmed in location 54. NOTE: Opening time must be earlier than closing time
for Auto Arm, Aux. Outputs, or Code Authorization to function properly.
Segment 1: Program the hour of the opening time.
Segment 2: Program the minutes after the hour of the opening time.
LOCATION 53 - CLOSING TIME/AUTOMATIC ARMING TIME (2 segments, numerical data)
Location 53 contains the time in 24 hour format the NX-4 disables the disarm capability for codes designated as arm
only after closing. This is also the time the Automatic Arming sequence will begin (if enabled in location 55). NOTE:
Opening time must be earlier than closing time for Auto Arm, Auxiliary Outputs, or Code Authorization to function
properly.
Segment 1: Program the hour of the closing / auto arm time.
Segment 2: Program the minutes after the hour of the closing / auto arm time.
LOCATION 54 - DAYS OF THE WEEK SYSTEM IS OPEN (1 segment, feature selection data)
Location 54 selects which days of the week system is open. On these days, Aarm only after close window@ codes will
be able to arm and disarm during open window. NOTE: If system is not programmed to be opened and is
programmed to Auto-Arm (Location 55), the NX-4 will try to arm every 45 minutes for the duration of the
closed period. On days not selected here, Aarm only after close window@ codes will not disarm. (See locations 52
and 53 for the opening and closing times for the open days.)
Segment 1: 1 - Open on Sunday.
2 - Open on Monday.
3 - Open on Tuesday.
4 - Open on Wednesday.
5 - Open on Thursday.
6 - Open on Friday.
7 - Open on Saturday.
8 - Reserved.
LOCATION 55 - DAYS OF THE WEEK FOR AUTO ARMING (1 segment, feature selection data)
Location 55 selects which days the system will auto arm. If a zone is faulted when the panel tries to auto arm, the
zone will be bypassed.
Segment 1: 1 - Auto Arming on Sunday.
2 - Auto Arming on Monday.
3 - Auto Arming on Tuesday.
4 - Auto Arming on Wednesday.
5 - Auto Arming on Thursday.
6 - Auto Arming on Friday.
7 - Auto Arming on Saturday.
8 - Reserved.

GE NetworX NX-4 Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP

Operating Environment

loop resistance	300 Ohms Maximum
loop response	500mS
operating temperature	32 to 120 degrees F

Weight and Dimensions

led keypad dimensions	6.4" Wide, 4.0" High, 1.1" Deep
nx-148e lcd keypad dimensions	6.4" Wide, 5.3" High, 1.0" Deep
metal enclosure dimension	9.25" Wide, 8.25" High, 3.50" Deep
