GE NetworX NX-4 User Manual

NX-4 Control
Page 22
COMMUNICATOR CODES FOR SLOW FORMATS ONLY
LOCATIONS 56- 83 ARE ONLY USED WHEN REPORTING EVENTS TO A PAGER OR USING A SLOW FORMAT
SUCH AS 4+2. WHEN USING CONTACT ID OR SIA, THERE IS NO NEED TO PROGRAM THESE LOCATIONS.
LOCATION 56 - ARESTORE@ CODE (1 segment, numerical data)
Location 56 contains the event code for any zone "Restore" for a 4+2 format. The digit programmed in this location
will be sent as the tens digit in place of the alarm event code. The zone ID will always be reported as the ones
digit of the zone number (i.e. 3 for zone 3).
LOCATION 57 - ABYPASS@ CODE (1 segment, numerical data)
Location 57 contains the event code for a zone "Bypass" for a 4+2 format. The digit programmed in this location will
be sent as the tens digit. The zone ID will always be reported as the ones digit of the zone number (i.e. 3 for
zone 3).
LOCATION 58 - ATAMPER@ CODE (1 segment, numerical data)
Location 58 contains the event code for a zone "Tamper" for a 4+2 format. The digit programmed in this location will
be sent as the tens digit. The zone ID will always be reported as the zone number (i.e. 3 for zone 3).
LOCATION 59 - ATROUBLE@ CODE (1 segment, numerical data)
Location 59 contains the event code for a zone "Trouble" for a 4+2 format. The digit programmed in this location will
be sent as the tens digit. The zone ID will always be reported as the zone number (i.e. 3 for zone 3).
LOCATION 60 - ASENSOR LOW BATTERY@ CODE (1 segment, numerical data)
Location 60 contains the event code for a zone "Sensor Low Battery" for a 4+2 format. The digit programmed in this
location will be sent as the tens digit. The zone ID will always be reported as the zone number (i.e. 3 for zone
3).
LOCATION 61 - ASENSOR MISSING@ CODE (1 segment, numerical data)
Location 61 contains the event code for a zone "Sensor Missing" for a 4+2 format. The digit programmed in this
location will be sent as the tens digit. The zone ID will always be reported as the zone number (i.e. 3 for zone
3).
LOCATION 62 - ADURESS@ CODE (2 segments, numerical data)
Location 62 contains the tens and ones digits that will be sent for a 4+2 format if the Duress code is enabled in
location 44. Segment 1 contains the tens digit, segment 2 contains the ones digit.
LOCATION 63 - AKEYPAD AUXILIARY 1" CODE (2 segments, numerical data)
Location 63 contains the tens and ones digits that will be sent for a 4+2 format if the keypad "Auxiliary 1" (FIRE) is
enabled in location 23. Segment 1 contains the tens digit, segment 2 contains the ones digit.
LOCATION 64 - AKEYPAD AUXILIARY 2" CODE (2 segments, numerical data)
Location 64 contains the tens and ones digits that will be sent for a 4+2 format if the keypad "Auxiliary 2" (MEDICAL)
is enabled in location 23. Segment 1 contains the tens digit, segment 2 contains the ones digit.
LOCATION 65 - AKEYPAD PANIC@ CODE (2 segments, numerical data)
Location 65 contains the tens and ones digits that will be sent for a 4+2 format if the keypad "Panic" is enabled in
location 23. Segment 1 contains the tens digit segment 2 contains the ones digit.
LOCATION 66 - AKEYPAD MULTIPLE CODE ENTRY TAMPER@ CODE (2 segments, numerical data)
Location 66 contains the tens and ones digits that will be sent for a 4+2 format if the keypad "Multiple Code Entry"
(Tamper) is enabled in location 23. Segment 1 contains the tens digit, segment 2 contains the ones digit.
LOCATION 67 - ABOX TAMPER / BOX TAMPER RESTORE@ CODES (4 segments, numerical data)
Location 67 contains the tens and ones digits that will be sent for a 4+2 format if the "Box Tamper" feature is enabled
in location 37. Segment 1 contains the tens digit of the "Box Tamper". Segment 2 contains the ones digit of the "Box
Tamper". Segment 3 contains the tens digit of the "Box Tamper Restore". Segment 4 contains the ones digit of the
"Box Tamper Restore".

GE NetworX NX-4 Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP

Operating Environment

loop resistance	300 Ohms Maximum
loop response	500mS
operating temperature	32 to 120 degrees F

Weight and Dimensions

led keypad dimensions	6.4" Wide, 4.0" High, 1.1" Deep
nx-148e lcd keypad dimensions	6.4" Wide, 5.3" High, 1.0" Deep
metal enclosure dimension	9.25" Wide, 8.25" High, 3.50" Deep
