NX-8 Control
26
AUXILIARY OUTPUT EVENT SELECTION
Table 1
DATA EVENT DATA EVENT
0 / Burglary Alarm 26 Fire Trouble
1 / Fire Alarm 27 Chime
2 / 24 Hour Alarm 28 / Expander Trouble
3 / Trouble Alarm 29 Dynamic Battery Test Time
4 / Tamper Alarm 30 Open Period
5 Yelping Siren (Burglary) 31 Closed Period
6 Temporal Siren (Fire) 32 Listen-In
7 Any Siren 33 Line Seizure
8 Any Bypass 34 Ground Start
9 AC Fail 35 Fail To Communicate
10 Low Battery 36 Telephone Line Fault
11 / Duress 37 Program Mode
12 / Aux 1 Keypad Zone 38 Download In Process
13 / Aux 2 Keypad Zone 39 Smoke Power
14 / Panic Keypad Zone 40 Short Circuit (Over-current)
15 Keypad Tamper 41 Box Tamper
16 / Autotest 42 Siren Tamper
17 Alarm Memory 43 Any Open
18 Entry 44 Any Short
19 Exit 45 Any Fault (Open/ Short on Non-Fire Zone)
20 Entry or Exit 46 / Any Alarm
21 Armed State 47 Beeping Keypad
22 Disarmed State 48 / Code Entry (See note below)
23 Ready 49 ˜ / Key FOB Function 1
24 Not Ready 50 ˜ / Key FOB Function 2
25 Fire
˜ Events 49 & 50 require NX-408E, NX-416E, or NX-448E wireless receivers to operate.
/ If set to follow condition, these events will be 1 second.
Notes : When Event 48 is programmed, it is possible to program a user code's authorization to select which output(s)
a particular code will activate. When LED 8 is on for an authorization, then LEDs 1- 4 correspond to that code
activating outputs 1 - 4 respectively. (See programming the LED keypads on page 9.)

GE NX-1308E - Caddx 8 Zone LED Keypad Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E power supply	12 VDC Regulated 2 AMPS
LED keypad current draw	130 mA max.
LED keypad zones normal w/o sounder	55 mA
NX-148E LCD keypad current draw	110 mA max.
NX-148E LCD keypad w/o sounder	75 mA

Operating Environment

operating temperature	32 to 120 degrees F

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Weight and Dimensions

LED keypad width	6.4"
LED keypad height	4.0"
LED keypad depth	1.1"
NX-148E LCD keypad width	6.4"
NX-148E LCD keypad height	5.3"
NX-148E LCD keypad depth	1.0"
metal enclosure width	11.25"
metal enclosure height	11.25"
metal enclosure depth	3.50"
shipping weight	9 lbs.
