GE NX-1308E - Caddx 8 Zone LED Keypad User Manual

ANSI / SIA CP-01 REQUIREMENTS
IMPORTANT NOTE: UL requirements take priority over SIA requirements.
To meet SIA CP-01 requirements –
•
Minimum System Requirements: 1 control panel; 2 keypads (or 1 keypad per partition for multi-partitioned systems)
• Remote arming shall NOT be enabled in SIA classified installations.
• Off-premise transmission must be in the SIA format.
• The Abort window and Entry Delay must not exceed 1 minute.
• CAUTION – A call waiting cancel on a non-call waiting line will prevent successful connection to the central station.
CP-01 Feature
Description
Feature Description
as shown in manual
Program
Loc
Seg / Opt
Factory
Default
CP-01 Required
Setting
Exit Time Exit 1 Delay
24
2
60
45 – 240 sec.
Exit 2 Delay
24
4
60
45 – 240 sec.
Progress Annuncation / Disable
– for Silent Exit
Silent Keypad Option
 9 3
2
All annunciators enabled Allowed
(individual keypads may be disabled)
Exit Time Restart This feature is non-programmable in the panel. Enabled
Auto Stay Arm on Unvacated Premises Auto Bypass
23
1 / 3
Enabled Enabled
Exit Time and Progress
Annunciation / Disable
– for Remote Arm
This feature is non-programmable in the panel. -- Exit time and progress are always enabled. Enabled (may be disabled for remote arming)
Entry Delay(s) Entry 1 Delay
24
1
30 30 – 240 sec.
Entry 2 Delay
24
3
30 30 – 240 sec.
Abort Window
– for Non-Fire Zones
Dialer Delay
40
8
30 Enabled
(may be disabled by zone/ zone type)
Abort Window Time
– for Non-Fire Zones
Dialer Delay
40
8
30 15 – 45 sec.
NOTE:
Combined
Abort window
and Entry
Delay must
not exceed 1
minute.
Abort Annunciation This feature is non-programmable in the panel. -- Flashing Cancel LED goes off when disarming. Enabled
Cancel Annunciation Cancel
23
3 / 6
Enabled Enabled
Duress Feature Duress
44
Disabled
Disabled
Cross Zoning
2 Trips on Cross Zone
37
5 / 4
Disabled
Required
Keypad sounds on Cross Zone trip
39
5
Disabled
Zone Type Characteristic
111
3 / 4
Disabled
Programmable Cross Zoning Time
Cross Zone Time
40
6
5 minutes
Allowed
Swinger Shutdown Swinger Shutdown Count
38
n/a
Enabled for 1 trip For all non-fire zones, shut down at 1–2 trips
Swinger Shutdown Disable Swinger Shutdown Count
38
n/a
Enabled for 1 trip Allowed
Fire Alarm Verification Fire Alarm Verification Time
40
9
Disabled Required (depends on panel & sensors)
Call Waiting Cancel
Must be programmed as part of the
phone number
0
n/a
n/a Required (depends on user phone line)
Default Changes (from prior versions):
Recent Closing
23
3 / 7
Enabled
Exit Error
23
3 / 8
Enabled
Power Up Delay
40
3
60 sec.

GE NX-1308E - Caddx 8 Zone LED Keypad Specifications

Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E power supply	12 VDC Regulated 2 AMPS
LED keypad current draw	130 mA max.
LED keypad zones normal w/o sounder	55 mA
NX-148E LCD keypad current draw	110 mA max.
NX-148E LCD keypad w/o sounder	75 mA

Operating Environment

operating temperature	32 to 120 degrees F

Loop Specifications

standard loop resistance	300 Ohms Maximum
2-wire smokes resistance	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Weight and Dimensions

LED keypad width	6.4"
LED keypad height	4.0"
LED keypad depth	1.1"
NX-148E LCD keypad width	6.4"
NX-148E LCD keypad height	5.3"
NX-148E LCD keypad depth	1.0"
metal enclosure width	11.25"
metal enclosure height	11.25"
metal enclosure depth	3.50"
shipping weight	9 lbs.
