GE NX-4-EUR

PARTITION 1, FEATURE SELECTION
Segment 1 Segment 2 Segment 3
1 Quick Arm 1 LED extinguish enable 1 Open/Close
2 Re-Exit 2 Require user code for bypassing zones
2 Bypass
3 Auto Bypass (interior) 3 Bypass sounder alert
3 Restore
4 Silent Panic
4 AC power/ low battery sounder alert 4 Trouble
5 Audible Panic 5 Enables bypass toggle
5 Tamper
6 Auxiliary 1 6 Enables silent auto arm
6 Cancel
7 Auxiliary 2 7 Enables automatic instant (entry/exit) 7 Recent Closing
8 Multi Keypress Tamper
8 Final set door 8 Exit Error
Segment 4 Segment 5
1 Late to close/early to open 1 Disables auto bypassing of force armable zones
2 Auto arm in stay mode 2 Reserved
3 Enables instant night 3 Reserved
4 Tamper when sensor lost if armed 4 Reserved
5 Enables instant stay toggle 5 Reserved
6 Arming with tamper mem./ comm. failure
6 Reserved
7 Arming with battery trouble 7 Reserved
23 41
8 Keyswitch zone arms in stay mode 8 Reserved
ENTRY/EXIT TIMERS
Segment 1 (Entry Time 1) 30
Segment 2 (Exit Time 1) 60
Segment 3 (Entry Time 2) 30
Segment 4 (Exit Time 2) 60
Reserved 0
24 42
Reserved 0
25 46 ZONES 1-8, CONFIGURATION GROUPS
3-5-6-6-6-6-6-6
26 46 Reserved
27 46 Reserved
28 46 Reserved
29 46 Reserved
31 46 Reserved
32 46 Reserved
33 46 Reserved
34 46 Reserved
35 46 Reserved
36 46 Reserved
NX-4-EUR Installation manual Page 76 02/07/06
