SIREN AND SYSTEM SUPERVISION
Segment 1 (Circle Numbers To Program)
1 Siren sounds for telephone line cut while armed
2 Siren sounds for telephone line cut while disarmed
3 Siren blast at arming (pulse)
4 Siren blast at exit delay expiration (pulse)
5 Siren blast at closing kissoff (pulse)
6 Siren sounds during a cross zone verification time
7 Siren sounds for a tamper
8 Siren blast once for keyswitch arming, twice for disarming
Segment 2 (Circle Numbers To Program)
1 Convert siren driver to voltage out
2 Siren sounds for expander trouble
3 Zones to always restore
4 Dynamic battery test performed upon arming
5 Battery missing test performed every 12 seconds
6 Manual bell test performed during [*]-[4]-[4] test function
7 Manual communicator test performed during [*]-[4]-[4] test function
8 Box tamper enabled
Segment 3 (Circle Numbers To Program)
1 Box Tamper report enabled
2 AC Fail report enabled
3 Low Battery report enabled
4 Auxiliary power overcurrent report enabled
5 Siren supervision report enabled
6 Restore Telephone Line Cut report enabled
7 A+B alarm
8 Expander trouble report enabled
Segment 4 (Circle Numbers To Program)
1 Failure To Communicate report enabled
2 Log Full report enabled
3 Autotest report enabled
4 Start and End Programming report enabled
5 End Download report enabled
6 Sensor Low Battery report enabled
7 Sensor Missing report enabled
8 Autotest report enabled ONLY when system is armed
Segment 5 (Circle Numbers To Program)
1 Lost Clock service LED enable
2 Enable zone doubling
3 Disable on-board zones
4 Enable two trips on the same cross-zone to activate the alarm
5 Disable bypass reports for force armed zones
6 Silent exit
7 Reserved
8 Automatic switch summer/wintertime and vice versa
Segment 6 (Circle Numbers To Program)
1 Reserved
2 Use internal crystal for clock
3 Enable zone activity in hours (not in days)
4 Enable first alarm logic
5 Enable log protection
6 Disable Clean Me report
7 Siren output is steady in case of fire alarm
37
46
8 User code will reset tamper memory
NX-4-EUR Installation manual Page 77 02/07/06
