Ordinal English Text Description Source
352 Out Of Step Conf Out of Step Confirmed (number of cycles reached) PSL (OUT)
353 S. Swing Conf Stable Swing confirmed (number of cycles reached) PSL (OUT)
354 Dist Start N Start of distance protection for phase to ground fault PSL (OUT)
355 IN>3 Trip
Trip decision from IN>3 function (timer issued)
Default PSL: Relay 09
PSL (OUT)
356 IN>4 Trip Trip decision from IN>4 function (timer issued) PSL (OUT)
357 IN>3 Start Start of IN>3 function (timer initiated) PSL (OUT)
358 IN>4 Start Start of IN>4 function (timer initiated) PSL (OUT)
359 PAP Trip A
Trip A Phase decision from PAP (specific application)
function
PSL (OUT)
360 PAP Trip B
Trip B Phase decision from PAP (specific application)
function
PSL (OUT)
361 PAP Trip C
Trip C Phase decision from PAP (specific application)
function
PSL (OUT)
362 PAP Trip IN
Trip decision from PAP (specific application) function
(Ground Fault detected)
PSL (OUT)
363 PAP Start A Phase A Start with PAP (specific application) function PSL (OUT)
364 PAP Start B Phase B Start with PAP (specific application) function PSL (OUT)
365 PAP Start C Phase C Start with PAP (specific application) function PSL (OUT)
366 PAP Pres IN
Residual current detected by PAP (specific application)
function
PSL (OUT)
367 PAP Pre Start
PAP (specific application) Picks up by voltage detectors
(timer initiated)
PSL (OUT)
368 Trace Trig OK Triggering trace has operated correctly PSL (OUT)
369 Thermal Alarm Alarm from Thermal Overload function picks up PSL (OUT)
370 Trip Thermal Trip with Thermal Overload fucntion (timer issued) PSL (OUT)
371 V<1 Start A Undervoltage stage 1 pick up on phase A PSL
372 V<1 Start B Undervoltage stage 1 pick up on phase B PSL
373 V<1 Start C Undervoltage stage 1 pick up on phase C PSL
374 V<2 Start A Undervoltage stage 2 pick up on phase A PSL
375 V<2 Start B Undervoltage stage 2 pick up on phase B PSL
376 V<2 Start C Undervoltage stage 2 pick up on phase C PSL
377 V>1 Start A Overvoltage stage 1 pick up on phase A PSL
378 V>1 Start B Overvoltage stage 1 pick up on phase B PSL
379 V>1 Start C Overvoltage stage 1 pick up on phase C PSL
380 V>2 Start A Overvoltage stage 2 pick up on phase A PSL
381 V>2 Start B Overvoltage stage 2 pick up on phase B PSL
382 V>2 Start C Overvoltage stage 2 pick up on phase C PSL
383 I2>2 Start Negative overcurrent stage 2 pick-up PSL
384 I2>3 Start Negative overcurrent stage 3 pick-up PSL
385 I2>4 Start Negative overcurrent stage 4 pick-up PSL
386 I2>2 Trip Negative overcurrent stage 2 trip PSL
387 I2>3 Trip Negative overcurrent stage 3 trip PSL
388 I2>4 Trip Negative overcurrent stage 4 trip PSL
389 VN>1 Start Neutral overvoltage stage 1 pick up PSL
390 VN>2 Start Neutral overvoltage stage 2 pick up PSL
391 VN>1 Trip Neutral overvoltage stage 1 trip PSL
392 VN>2 Trip Neutral overvoltage stage 2 trip PSL
393 Any Int. Trip Any Internal trip PSL
394 Zq Fault in zone Q PSL
395 Tzq Timer in zone Q elapsed (at 1 = end of timer) PSL
