MiCOM P40 Agile P442, P444
Relay 3 - M5-M6 HB relay 20 - J15(–)-J16(+)
Relay 4 - M7-M8 Relay 21 - H1-H2
Relay 5 - M9-M10 Relay 22 - H3-H4
Relay 6 - M11-M12 Relay 23 - H5-H6
Relay 7 M13-M15 M14-M15 Relay 24 H7-H9 H8-H9
Relay 8 M16-M18 M17-M18 Relay 25 H10-H12 H11-H12
HB relay 9 L3(–)-L4(+) Relay 26 H13-H15 H14-H15
HB relay 10 L7(–)-L8(+) Relay 27 H16-H18 H17-H18
HB relay 11 L11(–)-L12(+) Relay 28 - G1-G2
HB relay 12 L15(–)-L16(+) Relay 29 - G3-G4
HB relay 13 K3(–)-K4(+) Relay 30 - G5-G6
HB relay 14 K7(–)-K8(+) Relay 31 G7-G9 G8-G9
HB relay 15 K11(–)-K12(+) Relay 32 G10-G12 G11-G12
HB relay 16 K15(–)-K16(+) Relay 33 G13-G15 G14-G15
HB relay 17 J3(–)-J4(+) Relay 34 G16-G18 G17-G18
Table 6 - Relay Output Terminals and Test Pattern Settings
Return the relay to service by setting cell [0F0E: COMMISSIONING TESTS, Test Mode] to
‘Disabled’.
4.2.9 Rear Communications Port
This test should only be performed where the relay is to be accessed from a remote location
and will vary depending on the communications standard being adopted.
It is not the intention of the test to verify the operation of the complete system from the relay
to the remote location, just the relay’s rear communications port and any protocol converter
necessary.
4.2.9.1 Courier Communications
If a K-Bus to RS232 KITZ protocol converter is installed, connect a portable PC running the
appropriate software to the incoming (remote from relay) side of the protocol converter.
If a KITZ protocol converter is not installed, it may not be possible to connect the PC to the
type installed. In this case a KITZ protocol converter and portable PC running appropriate
software should be temporarily connected to the relay’s K-Bus port. The terminal numbers
for the relay’s K-Bus port are given in Table 7. However, as the installed protocol converter
is not being used in the test, only the correct operation of the relay’s K-Bus port will be
confirmed.
Connection Terminal
K-Bus Modbus or VDEW P442 P444
Screen Screen J16 N16
1 +ve J17 N17
2 –ve J18 N18
Table 7 - RS485 Terminals
Ensure the communications baud rate and parity settings in the application software are set
the same as those on the protocol converter (usually a KITZ but could be a SCADA RTU).
The relay’s Courier address in cell [0E02: COMMUNICATIONS, Remote Address] must be
set to a value between 0 and 255.
Check that communications can be established with this relay using the portable PC.
