GE PFSS5NJWSS

15
Fresh Food Damper (cont.)
5. Pull up on the damper assembly then remove the air tower cover.
6. Disconnect the damper motor wire harness.
7. Carefully remove the tape and gasket.
mabe CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. January 2008
