Articulating Door Mullion (French Door
Models)
The articulating door mullion is attached to the right side door, and provides a
movable center mullion that maximizes access to the fresh food compartment.
With both refrigerator doors closed or only the left side door opened, the
mullion stays in position. When the right side door is opened, the spring loaded
mullion is activated to fold against the handle side of the door liner.
The pin on top of the mullion and the track, located at the top center front of
the refrigerator, ensure proper mullion bar alignment upon closure of the right
side door.
Door closed-pin
in track
Door opening-pin
exiting track
