Inverter Compressor
Do not attempt to direct-start the compressor. The compressor
operates on a 3-phase power supply. Applying 120 VAC to the
compressor will permanently damage the unit. It is not possible to start
the compressor without an inverter.
The compressor is a reciprocating, variable speed, 4-pole type. It operates on 3-
phase, 80 to 230 VAC within a range of 57 to 104 Hz.
Note: Certain voltmeters will not be able to read voltage output or frequency
from the inverter.
Compressor wattages at various speeds are:
•LOW -65 watts
• MED - 100 watts
• HIGH - 150 watts
The compressor is controlled by the inverter, which receives its signal from the
main control board. Varying the frequency to the inverter changes the
compressor speed.
