Icemaker Fill Tube Heater
•The fill tube heater is energized during the defrost cycle when the defrost
thermostat is closed.
•Remove the evaporator fan cover to access the icemaker fill tube heater.
(See How to access the evaporator)
•Disconnect the fill tube heater wire harness.
•The resistance of the fill tube heater is approximately 2644 ohms.
