14
Fresh Food Damper
• The damper assembly consists of a motorized damper that is housed inside the
damper air tower. The damper is connected by a wire harness. The damper
assembly is held in place with a single ¼-in. hex-head screw and 2 pins.
To remove the fresh food damper:
1. Remove the fruit and vegetable crisper drawers and the crisper drawers’ cover and
frame assembly.
Caution: The glass inserted in the deli pan cover and frame may easily
separate. Care should be taken when removing the deli pan cover and
frame assembly.
2. Partially open the deli pan, lift and remove the deli pan cover and frame.
3. Pull the deli pan out to the fully open position
4. Remove the ¼-in. hex-head screw from the air tower cover.
mabe CONFIDENTIAL AND PROPRIETARY INFORMATION-NOT FOR PUBLIC DISCLOSURE. January 2008
