How to access the evaporator (cont.)
• Note: The top of the vertical divider is inserted in a molded recess in the
freezer ceiling. The bottom of the divider has a front and rear tab that
are captured in a notch in each of the 2 support rails.
6. Remove the vertical divider from the support rails.
a) Release the front of the vertical divider by pressing down on the front
support rail while applying upward pressure the front of the divider.
