8 49-2000989 Rev. 2
USING THE RANGE:6XUIDFH8QLWV
Surface Units
How Induction Surface Cooking Works
The magnetic fields induce a small current in the pan.
The pan acts as a resistor, which produces heat, much
like a radiant coil.
The cooking surface itself does not heat. Heat is
produced in the cooking pan, and cannot be generated
until a pan is placed on the cooking surface.
When the element is activated, the pan begins to heat
immediately and in turn heats the contents of the pan.
Magnetic induction cooking requires the use of cookware
made of ferrous metals—metals to which magnets will
stick, such as iron or steel.
8VHSDQVWKDWILWWKHHOHPHQWVL]H7KHSDQPXVWEHODUJH
enough for the element to detect the pan and be able to
deliver full power.
The cooktop will not operate if a very small steel or iron
utensil, such as a steel spatula, cooking spoon, knife
or other small utensil, is placed on the cooking surface
when the unit is turned on.
CAUTION
Ŷ 7KHLQGXFWLRQFRRNLQJHOHPHQWVPD\DSSHDUWREHFRRO
while turned ON and after they have been turned OFF.
The glass surface may be HOT from residual heat
transferred from the cookware and burns may occur.
Ŷ '2127728&++27&22.:$5(RU3$16GLUHFWO\
with hands. Always use mitts or pot holders to protect
hands from burns.
Ŷ '21276/,'(FRRNZDUHDFURVVWKHFRRNWRSVXUIDFH
Doing so may permanently damage the appearance of
the ceramic cooktop.
Operating the Cooktop Elements
WARNING
FIRE HAZARD: Never leave the
range unattended with the cooktop on. Keep
flammable items away from the cooktop. Turn off all
controls when done cooking. Failure to follow these
instructions can result in fire, serious injury or death.
Before using the cooktop for the first time, clean it with
ceramic cooktop cleaner. This helps protect the top and
makes cleanup easier.
Turn element(s) On: Touch and hold On/Off pad about
half a second. A chime can be heard with each touch to
any pad.
Power level can be selected in any of the following ways:
1. Swipe the gray arc (on the graphics) to the desired
power level. There is no sensor on the LEDs, or;
2. Touch Anywhere along the gray arc, or;
3. Touch + or - pads to adjust power level, or;
4. Shortcut to Hi: Immediately after turning unit on, touch
the + pad, or;
5. Shortcut to Low: Immediately after turning unit on,
touch the - pad.
8VHWKHPLQLPXPVL]HSDQIRUWKHHOHPHQW7KH
pan material is correct if a magnet sticks to the
bottom.
Min. Size
Min. Size
Gray Arc
Swipe Area
LED
Lights
Gray Arc
Swipe Area
OR
To Next Page
