– 28 –
Schematics
Caution: Label all wires prior to disconnection when
servicing the controls. Wiring errors can cause
improper and dangerous operation. Verify proper
operation after servicing.
L
RED
RED
RAISE/LOWER
SWITCH
FAN ON/OFF
SPEED CONTROL SWITCH
R
R
R
BLACK
TOP BURNER IGNITERS
BLACK
BLACK
BLACK/WHITE
BLACK/WHITE
MICROSWITCH
TOP/BOTTOM LIMITS
WHITE
WHITE
WHITE
WHITE
WHITE
WHITE
TOP BURNER IGNITION SWITCHES
WHITE
N
N
L
PURPLE
WHITE
GREEN
BLUE
IGNITION
UNIT
THESE COMPONENTS MAY NOT
APPEAR ON ALL MODELS
W
W
W
FAN
MOTOR
RAISE/LOWER
MOTOR
MICROSWITCH
FAN CUTOUT
GEA00586
