– 31 –
Model JGP656WB0WW
View Catalog Description Qty.
1 WB02X9857 SEAL-COOKTOP TO WORKTOP 2
1 31-20775 MINI-MANUAL (SNORKEL) 1
1 49-80011 PM USE & CARE MANUAL 1
2 WB02X9857 SEAL GASKET 4
3 WB28K0145 ORIFICE LP .78 LMM 2
3 WB28K10022 ORIFICE-NG 1.50MM 2
3 WB28K10029 ORIFICE-NG 1.07MM 1
3 WB28K10030 ORIFICE-NG 1.68MM 1
3 WB28K10031 ORIFICE-LP .63MM 1
3 WB28K10107 ORIFICE SPUD LP .84MM 1
4 WB63K10022 CONTAINER BOX ASSEMBLY 1
8 WB21K10006 VALVE BURNER LFT RR 1
9 WB21K10007 VALVE BURNER RT RR 1
10 WB21K10005 VALVE BURNER RT FRONT 1
11 WB21K10008 VALVE BURNER LEFT FRONT 1
13 WB02K10036 BRACKET BURNER 4
14 WB01X1192 FLAT WASHER-M4 30
16 WB19K0026 PRESSURE REGULATOR 1
18 WB02K0108 COVER VALVE 5
21 WB01K0083 SCREW-MTG VALVE BURNER 5
30 WB34K10042 SHIELD SPARK MOD 1
31 WB35K10023 INSULATION-SPK MODULE 1
38 WB24K10001 BLOWER SPEED REGULATOR 1
40 WB24X0475 SWITCH 1
42 NOT STOCKED SHIELD-SWITCH 1
44 WB01X1382 HEX NUT 3/8" X 32 1
48 WB01X1383 FIBRE WASHER 10MM 2
50 WB02K10001 MOUNTING PLATE ELEC 1
51 WB06K0014 ADAPTOR 1
52 WB28K10106 INLET BLOCK 1
54 WB02X9836 GROUND POST ASSEMBLY 1
56 WB02X9838 POWER CORD CLAMP 1
58 WB18X0380 POWER SUPPLY CORD 1
60 NOT STOCKED SHIELD-TERMINAL BLOCK 1
62 NOT STOCKED TERMINAL BLOCK 1
64 WB01X1189 SCREW M4X8 21
66 WB18K10001 HARNESS-MAIN WIRING 1
66 WB18K10010 HV WIRE HARNESS 1
72 WB13K10007 ELECTRODE SPARK 5
74 WB01K10026 CLIP ELECTRODE 5
75 WB02K10037 GROUND PATH SHIELD 5
86 WB57K10052 GLASS COOKTOP-WH 1
88 WB02X9843 SEAL-DRIP PAN 5
91 WB02X9243 INSTALLATION HARDWARE PK 2
94 WB02K10044 RETENTION BRACKET 5
95 WB34K10043 CLAMPING PLATE 5
View Catalog Description Qty.
96 NOT STOCKED NUT M4 30
101 WB56X10010 COVER 36" 1
102 WB56X10004 PANEL GEAR MOTOR 1
103 WB07X10012 SLIDE 1
104 WB02X10303 PIVOT ARM 1
106 WB02X10306 ROLLER 1
108 WB02X10310 FILTER 2
109 WB02X10307 SEAL 1
110 WB13K10005 SPARK MODULE 5+0 1
112 WB31K10059 GRATE DOUBLE 2
113 WB02X10308 BLOWER SUPPORT LEGS 8
114 WB28K10108 MANIFOLD PIPE ASM 1
115 WB32K10021 PAN UNIT LEFT FRT & RR 2
115 WB32K10022 DRIP PAN RT REAR WH 1
115 WB32K10024 DRIP PAN RT FRONT WH 1
116 WB28K10102 SUPPLY TUBE-LEFT FRONT 1
118 WB28K10100 SUPPLY TUBE-LEFT REAR 1
122 WB28K10101 SUPPLY TUBE -RIGHT REAR 1
123 WB01X10004 U-BOLT 1
124 WB28K10099 SUPPLY TUBE-RIGHT FRONT 1
125 WB18K10011 HARNESS SWITCH 1
126 NOT STOCKED BASEPLATE 1
127 WB28K10105 SUPPLY TUBE MAIN 1
128 WB01K10025 SCREW-MTG SUPPLY TUBE 1
129 WB27X5599 CAPACITOR 1
133 WB01X10007 BUTTON SLIDE 4
135 WB01X10008 SCREW, PAN HEAD 2
138 WB07X1832 BEZEL-WHITE 5
140 WB03K10106 KNOB BURNER (GRAY) 4
142 WB03K0103 KNOB-DOWNDRAFT CTL GRAY 2
145 WB01K10005 NUT 6-32- MTG GLASS TRIM 4
146 WB34K10002 WIRE BOX 1
147 WB26X10005 GEAR MOTOR 1
148 WB38X5079 BLOWER 1
149 WB01X10006 HEYCO BUSHING 1
150 WB02X10309 SEAL 2
151 WB29K10002 CAP-BURNER SMALL (GRAY) 1
152 WB29K10004 CAP-BURNER MED (GRAY) 2
153 WB29K10007 CAP-BURNER LARGE (GRAY) 1
155 WB16K10014 BURNER-SMALL 1
156 WB16K10005 BURNER-MED 2
157 WB16K10007 BURNER-LARGE 1
167 WB01X10003 SCREW BLACK 25
169 WB02X10301 FORMED BOX 1
170 WB61K10002 GLASS-SNORKEL-WHITE 1
