Installation Instructions
INSTALL FILTERS
Charcoal Filter
Insert the charcoal filter into the opening.
Push the latch on both sides toward the center
and engage the flange.
Metal Grease Filter
• Remove the protective film on the grease filter.
• Fit the tabs at the end of the filter into the slots
in left side of the filter opening. Lift up the right
side of the filter and push gently until the filter
locks into place. Make sure the filter lock is
in the closed position to secure the filter.
• To remove the filter, pull downward on the filter
lock to release.
8
FINALIZE INSTALLATION
• Remove all tape and packaging materials.
• Refer to the Operating Instructions in this manual
to operate the hood.
9
22
INSTALLATION—RECIRCULATING
