GE RAK160W2 - Wireless Control Card Installation

49-5000637 Rev. 0 7
Thermostat Installation
Installing the Wireless Control Card
• Power off the Zoneline
• Insert the Control Card wiring harness into the thermostat
connection port on the front of the Zoneline control box cover.
AC input
Remote
Thermostat
Connection
Red Aux Set
Button
Image 1
