– 41 –
Note: VSD = Inverter
Error Code Component Description Procedure
E10 EOL EOL Water Inlet Test Code not cleared at "End Of Line" factory test, clear error and continue
E11 EOL EOL Agitation Test Incomplete Code not cleared at "End Of Line" factory test, clear error and continue
E12 EOL EOL Drain Test Incomplete Code not cleared at "End Of Line" factory test, clear error and continue
E13 EOL EOL Spin Test Incomplete Code not cleared at "End Of Line" factory test, clear error and continue
E20 Fill System Low Level Pressure Switch Error Check pressure switch, pressure hose, wiring or control
E21 Fill System High Level Pressure Switch Error Check pressure switch, pressure hose, wiring or control
E30 Drive System Clog Detected Check drain pump, drain line
E31 Drive System Pump Timeout Check for pump clog, drain line, pressure switch
E32 Drive System Pump Current Detection Circuit Error Check pump current in Service Mode (page 37). Normal is 1.5 to 3.5 amps
E40 Drive System
VSD (Variable Speed Drive)
Health Error
Check if washer can spin and agitate. If not, check for 5 VDC between black
and white at inverter connector CN9. Replace inverter if present.
E41 Drive System VSD Power/Communication Error Check inverter power supply, wiring or control.
E42 Drive System
VSD (Variable Speed Drive)
Noisy Communication Error
Check wiring and make sure all ground connections are good, especially
the braided cable between base and motor platform.
E43 Drive System Excessive Brake Time Check brake. Check speed sensor if brake check OK.
E46 Drive System VSD No Speed Signal Check speed sensor, wiring, or control
E47 Drive System
VSD (Variable Speed Drive)
Heat Sink Over Temperature
Check inverter, could have been a very large load or jammed agitator
in wash cycle
E48 Drive System VSD Motor Short Circuit Check motor resistance, check inverter to motor harness.
E49 Drive System
VSD (Variable Speed Drive)
Drive Overload
Check inverter, could have been a very large load or jammed agitator
in wash cycle
E4A Drive System
VSD (Variable Speed Drive)
Line Voltage Failure
Check inverter power, could be loose power connection at outlet,
at control, or at inverter.
E4B Drive System
VSD (Variable Speed Drive)
Drive Reset
Low voltage (most likely cause is a brownout). Check whether washer
can agitate and spin under a large load.
E4C Drive System
VSD (Variable Speed Drive)
Temperature Sensor Failure
Check inverter, could have been a very large load or jammed agitator
in wash cycle
E4D Drive System
VSD (Variable Speed Drive)
Ram Error
Check inverter, could have been a very large load or jammed agitator
in wash cycle
E50 Electronic Control EEPROM Read/Write Failure
Try to reprogram EEPROM in Service Mode (see page 37).
If EEPROM will not reprogram, replace control
E60 Sensors Lid Switch Error Check lid switch, wiring or control
E61 Sensors Speed Sensor Error Check speed sensor, magnets, wiring or control.
E62 Sensors Lid Lock Error Check lid lock, speed sensor, wiring or control
E63 Sensors Excessive Radial Acceleration Code not cleared at "End Of Line" factory test, clear error and continue
E64 Sensors Excessive Axial Acceleration Code not cleared at "End Of Line" factory test, clear error and continue
E65 Sensors Accelerometer No Signal Error Check accelerometer, wiring, or control
E66 Sensors Water Temperature Sensor Open Check thermistor, wiring, or control
E67 Sensors Water Temperature Sensor Short Check thermistor, wiring, or control
Error Codes Table
