10.1Capacityregulator
Fig.18
CR1
CR2
ATTENTION Ifthecapacityregulatorisinstalledatthefactory,itissubsequently
installedandconnectedbythecustomer.
10 | Accessories
CR1
Deliverycondition1(fromthefactory):
Cylindercoverpreparedforcapacityregulator.
Fig.20
Before commissioning, the blind flange with
screwsmustberemovedandreplacedbythe
new set capacity regulator with O-ring joints
andscrews.Observepositionandconstruction
ofthecapacityregulator.
Attention!Compressorisunderpressure!
Depressurizethecompressorfirst.
Deliverycondition2(fromthefactory):
Connectcapacityregulatorinterminalboxor
switchcabinet.
Fig.19
Fig.21
HG44e HG56e
