• HG44e:Semi-hermeticfour-cylinderreciprocatingcompressorwithsuction-gascooleddrivemotor.
• HG56e:Semi-hermeticsix-cylinderreciprocatingcompressorwithsuction-gascooleddrivemotor.
• Preferredapplicationrange:normalrefrigeratingandair-conditioning.
3| Product description
Nameplate
Fig.1
3.1 Short description
Valveplate
Cylinder
cover
DimensionandconnectionvaluescanbefoundinChapter 12
Transporteyelet
Discharge
shut-offvalve
Oilpump
Suction
shut-offvalve
Oilsightglass
Drivesection
Motorsection
Fig.2
HG44e
HG56e
Terminal
box
