Suction line
Discharge line
see technical data, Chapter 9
A
Connection suction side, not lockable
1
/
8
“ NPTF
A1
Connection suction side, lockable
7
/
16
“ UNF
A2
Connection suction side, not lockable
1
/
4
“ NPTF
B
Connection discharge side, not lockable
1
/
8
“ NPTF
B1
Connection discharge side, lockable
7
/
16
“ UNF
C
Connection oil pressure switch OIL
7
/
16
“ UNF
D
Connection oil pressure switch LP
7
/
16
“ UNF
D1
Connection oil return from oil separator
1
/
4
“ NPTF
E
Connection oil pressure gauge
7
/
16
“ UNF
F
Oil drain M22x1,5
H
Oil charge plug M33x2
J
Connection oil sump heater M22x1,5
K
Sight glass -
L
Connection thermal protection thermostat
1
/
8
“ NPTF
N
Connection capacity controller M45x1,5
O
Connection oil level regulator 3 x M6
ÖV1
Oil service valve
7
/
16
“ UNF
P
Connection oil differential pressure sensor M20x1,5
Q
Connection oil temperature sensor
1
/
8
“ NPTF
10| Dimensions and connections
