2| Product description
/
HG 8
3220-
4
X
Fig. 2
2.2 Name plate (example)
2.3 Type key (example)
¹
)
HG - Hermetic Gas-cooled (suction gas-cooled) for the normal- / air conditioning applications
²
)
X - Ester oil charge (HFC refrigerant, e.g. R134a, R404A/R507, R407C)
3)
S - More powerful motor, e.g. for air-conditioning applications
Motor variant
3)
Number of poles
Swept volume
Size
Oil charge ²
)
Series ¹
)
S
50 Hz
}
60 Hz
}
Observe the limits of application
diagrams!
1 Type designation
2 Machine number
3 Type code
4 Maximum operating current
5 Starting current (rotor blocked)
Y: Part winding 1
YY: Part windings 1 and 2
6 ND (LP): max. admissible operating
pressur e (g) Low pressure side
HD (HP): max. admissible operating
pressur e (g) High pressure side
7 Voltage,circuit,frequency
8 Nominal rotation speed
9 Displacement
10 Voltage,circuit,frequency
11 Nominal rotation speed
12 Displacement
13 Oiltypelledatthefactory
14 Terminal box protection type
Electrical accessories can change
the IP protection class!
SE 55
AS12345-A018
HGX8/3220-4
GEA Bock GmbH
72636 Frickenhausen, Germany
AW09529A047
2
1
3
4
5
7
8
9
10
11
12
13
14
6
Oil
Y/YY
Y/YY
