40
09665-08.2018-Gb
12 I Assembly of compressor
1
Fitting the roller bearings
Position in
parts list
Parts list position: 2150
Tools: Pressing apparatus
Working course
730
312
2150
- Heat the bearing ange / compressor casing for approx. 20 minutes in a pre-heated (120°C) baking oven
- Insert tolerance ring into the roller bearing, if available
- Press the roller bearings onto the compressor casing and the front bearing ange
CAUTION Risk of burns!
Parts are hot! Use protective gloves!
INFO Use tolerance ring if the bearing seat has a groove!
