56
09665-08.2018-Gb
Spare parts list
Pos. Designation Version Piece
FK(X)40/ ...
390 470 560 655 755
1)
20 Baseplate N, K, TK 1 03876 03876 03876 03876 03876
30 Baseplate gasket N, K, TK 1 06721 06721 06721 06721 06721
40 Hexagon head screw M8x30 N, K, TK 26 06244 06244 06244 06244 06244
50 Lower valve plate gasket Ø 55 N, TK
2 05695 05695 - - -
50 Lower valve plate gasket Ø 60 N, TK
2 - - 05696 - -
50 Lower valve plate gasket Ø 65 N, TK
2 - - - 05697 -
60 Valve plate, complete Ø 50 / 55 N, TK
2 07117 07117 - - -
60 Valve plate, complete Ø 60 / 65 N, TK
2 - - 07118 07118 -
70 Upper valve plate gasket N, TK
2 06730 06730 06730 06730 -
100 Decompression valve for 28 bar operation N, K, TK
1 07940 07940 07940 07940 07940
170 Cylinder cover N, TK
2 03384 03384 03384 03384 -
180 Hexagon head screw M10x65 N, TK
22 06034 06034 06034 06034 -
181 Disc A10.5 N, K, TK
22 05646 05646 05646 05646 05646
199 Transport angle N, K, TK
1
50435 50435 50435 50435 50435
210 Valve ange gasket N, K, TK
3 50636 50636 50636 50636 50636
220 Hexagon head screw M10x65 N, K, TK
4 06034 06034 06034 06034 06034
221 Disc A10.5 N, K, TK
3 05646 05646 05646 05646 05646
230 Filter suction side N, K, TK
1 03370 03370 03370 03370 03370
231 O-Ring Ø 34.59x2.62 N, K, TK
1 05153 05153 05153 05153 05153
232 Blind ange 9 mm N, K, TK
1 04715 04715 04715 04715 04715
233 Countersunk screw M10x25 N, K, TK
2 05075 05075 05075 05075 05075
270 Piston pin Ø 15x10x41 N, K, TK
4 07211 - - - -
270 Piston pin Ø 15x10x46 N, K, TK
4 - 07212 - - 07212
270 Piston pin Ø 15x10x50 N, K, TK
4 - - 07857 07857 -
280 Seeger circlip 15x1, DIN 472 N, K, TK
8 05551 05551 05551 05551 05551
290 Oil scraper ring piston 50 N, K, TK
4 05389 - - - -
290 Oil scraper ring piston 55 N, K, TK
4 - 05390 - - -
290 Oil scraper ring piston 60 N, K, TK
4 - - 06562 - -
290 Oil scraper ring piston 65 N, K, TK
4 - - - 06572 -
290 Oil scraper ring piston 70
K 4 - - - - 51079
300 Tapered compression ring piston 50 N, K, TK
4 05379 - - - -
300 Tapered compression ring piston 55 N, K, TK
4 - 05380 - - -
300 Tapered compression ring piston 60 N, K, TK
4 - - 06563 - -
300 Tapered compression ring piston 65 N, K, TK
4 - - - 06564 -
300 Tapered compression ring piston 70
K 4 - - - - 51080
312 Tolerance ring for bearing Ø 90 N, K, TK
2 05280 05280 05280 05280 05280
320 Cap nut M22x1.5 N, K, TK
2 05784 05784 05784 05784 05784
321 Cap nut 7/16“ UNF N, K, TK
2 51714 51714 51714 51714 51714
322 Screw plug 1/8“ NPTF N, K, TK
2 05514 05514 05514 05514 05514
330 Shut-off valve (AL) N, K, TK
2 07128 07128 07128 07128 07128
340 Gasket ring 42x34x1 N, K, TK
2 05067 05067 05067 05067 05067
2)
350 Soldered bush Ø 22 N, K, TK
1 04366 - - - -
350 Soldered bush Ø 28 N, K, TK
1 - 04367 04367 - -
350
Soldered bush Ø 35 N, K, TK
1 - - - 05313 05313
2)
355 Flange oval 16 mm N, K, TK
1 04329 04329 04329 04329 04329
2)
360 Flange oval 16 mm N, K, TK
1 04329 04329 04329 04329 04329
2)
370 Hexagon head screw M10x35 N, K, TK
2 05447 - - - -
370 Cylinder screw M10x35 N, K, TK
2 - 50287 50287 50287 50287
2)
13 I Parts list
