57
09665-08.2018-Gb
Pos. Designation Version Piece
FK(X)40/ ...
390 470 560 655 755
1)
380 Hexagon head screw M10x35 N, K, TK
2 05447 05447 05447 - -
380 Cylinder screw M10x35 N, K, TK
2 - - - 50287 50287
2)
400 Soldered bush Ø 28 N, K, TK
1 04367 - - - -
400 Soldered bush Ø 35 N, K, TK
1 - 05313 05313 05313 05313
2)
460 Oil pump complete N, K, TK
1 07990 07990 07990 07990 07990
470 Gasket for oil pump + rear bearing flange N, K, TK
1 05094 05094 05094 05094 05094
490 Oil filter N, K, TK
1 06723 06723 06723 06723 06723
500 Seal ring 27x22x2 N, K, TK
1 05342 05342 05342 05342 05342
510 Screw plug M22x1.5 N, K, TK
1 06400 06400 06400 06400 06400
520 Screw plug 1/8“ NPTF N, K, TK
2 05514 05514 05514 05514 05514
521 Screw plug 1/4“ NPTF N, K, TK
2 05801 05801 05801 05801 05801
570
Sight glass - insert Ø 18
up to type code 012
N, K, TK
2 06026 06026 06026 06026 -
570
Sight glass - insert Ø 22
from type code 013
N, K, TK
2 05361 05361 05361 05361 05361
590 O-Ring Ø 23.52x1.78 up to type code 012 N, K, TK
2 05142 05142 05142 05142 -
590 O-Ring Ø 28.30x1.78 from type code 013 N, K, TK
2 06352 06352 06352 06352 06352
726 Cylinder screw M10x10 N, K, TK
1 06169 06169 06169 06169 06169
727 Cable / hose holder N, K, TK
1 03860 03860 03860 03860 03860
728 Cable / hose clamp N, K, TK
1 03861 03861 03861 03861 03861
729 Haft plug Ø 5 (PHT, SCHW.) N, K, TK
1 50184 50184 50184 50184 50184
730 Front bearing flange N, K, TK
1 06726 06726 06726 06726 06726
740 Front bearing flange gasket N, K, TK
1 06165 06165 06165 06165 06165
745 O-Ring Ø 101.19x3.53 N, K, TK
1 05169 05169 05169 05169 05169
750 Cylinder screw M8x25 N, K, TK
14 06067 06067 06067 06067 06067
790 Woodruff key A5x9 DIN 6888 N, K, TK
1 05673 05673 05673 05673 05673
800 Disc Ø 50x12.5x8 N, K, TK
1 04425 04425 04425 04425 04425
2)
810 Spring washer B12 N, K, TK
1 05666 05666 05666 05666 05666
2)
820 Hexagon head screw M12x40 N, K, TK
1 05462 05462 05462 05462 05462
2)
880 Shaft seal cover gasket N, K, TK
1 05063 05063 05063 05063 05063
1910 Lower valve plate gasket Ø 50
K 2 06178 - - - -
1910 Lower valve plate gasket Ø 55
K 2 - 06161 - - -
1910 Lower valve plate gasket Ø 60
K 2 - - 06641 - -
1910 Lower valve plate gasket Ø 65
K 2 - - - 06642 -
1910 Lower valve plate gasket Ø 70
K 2 - - - - 51478
1920 Valve plate complete
K 2 07700 07700 07700 07700 51479
1930 Upper valve plate gasket
K 2 06162 06162 06162 06162 06162
1940 Cylinder cover
K 2 03381 03381 03381 03381 03381
1950 Hexagon head screw M10x70
K 22 05457 05457 05457 05457 05457
Only for FK compressors:
3999 Mach. oil SP46 / 1 ltr. can N, K, TK
1 02279 02279 02279 02279 02279
3999 Mach. oil SP46 / 5 ltr. can N, K, TK
1 02280 02280 02280 02280 02280
3999 Mach. oil SP46 / 20 ltr. can N, K, TK
1 02281 02281 02281 02281 02281
Only for FKX compressors:
3999 Mach. oil SE55 / 1 ltr. can N, K, TK
1 02282 02282 02282 02282 02282
3999 Mach. oil SE55 / 5 ltr. can N, K, TK
1 02283 02283 02283 02283 02283
3999 Mach. oil SE55 / 10 ltr. can N, K, TK
1 02284 02284 02284 02284 02284
13 I Parts list
1)
only version K available
2)
not included in standard scope of delivery
